Project Status



Project Type:  Borehole Well and Hand Pump

Regional Program: Port Loko, Sierra Leone WaSH Program

Impact: 82 Served

Project Phase:  In Service - Apr 2024

Functionality Status:  Functional

Last Checkup: 12/17/2024

Project Features


Click icons to learn about each feature.



Community Profile

The 82 people who live in this area of Komrabai rely on the local swamp for water. Without it, there would not be sufficient water to meet their daily needs, but understandably, using it as their primary water source creates multiple problems.

For 15-year-old Mbalu (shown below collecting water), fetching water here is especially scary.

"The road leading to this source is bushy and dangerous," said Mbalu. "Animals like snakes reside in the bush. I was once attacked by a very big cobra at the stream. If not for the intervention of the youth that was around, I should have lost my life that day. Due to this situation, I was terrified of going to the stream alone unless someone accompanies me."

But her fear is not the only issue. The swamp is far away from the community, and the water gets stirred up, needing time to settle after each person collects water. Therefore, a lot of time is consumed both collecting and waiting for water.

"The only option for me is stream water, but this source is located far from the community," said Mbalu. "Apart from this, fetching drinking water would be difficult for me since the water at the stream easily changes in color. I would wait for over an hour just for the water to regain its original color. These waiting times make me go late at home, and my parents would be angry with me, failing to understand the cause of my action."

Mabinty Kamara, a 38-year-old petty trader, also wastes her valuable time at the swamp. "Although the stream does not [dry out], the water at the stream becomes dirty to the point that I must wait to fetch water, especially for drinking purposes. The reason for this situation is that we must enter the stream with our feet. A lot of people enter the stream on [a] daily basis with bare feet and different containers. During such situations, the water at the stream gets extremely dirty."

Mabinty continued: "Another challenge that is attached to the stream water source is the hill that is difficult to climb. Climbing the hill with heavy containers of water on my head is really difficult. With the slightest mistake, one would easily fall to the ground."

There is a community well (the one in need of rehabilitation, shown below), but it faces several issues, the first being that it's overcrowded since it's used by people from multiple communities.

"It is very difficult to access water in my community because our main water source is congested with a lot of people, especially in the morning hours. This situation leads me to [take a long time] since the competition would be high at the water point," said Mbalu.

"The only water well in this community is not enough for us," said Mabinty. "A lot of people from other villages would fetch water at our main source. This situation has led to a high demand of water in the community. During such instances, some of us would not be able to get water at the time we need it. This has affected my activities at home, and even the trade that I am doing."

The well is also unreliable in producing enough water, especially during the dry season when the water levels are lower, and it is slow to recharge. Sadly, the water it can produce is often dirty and muddy, making it less than desirable to use, especially for drinking. And for at least a couple of months a year, the water dries up completely, and people have no choice but to resort to the swamp.

"There are times the water source produced low water in the dry season, and the water gets dirty. Unless they lock the pump so that water will flow enough before the pump is open," said Mbalu.

"I would be happy if our well would become functional again. All the water constraints I am presently undergoing would definitely become a thing of the past," Mabinty concluded.

By rehabilitating the well and making it deeper, water should be available in the community throughout the entire year without concerns for its quality. And Mbalu and fellow community members should be able to quickly and safely collect the water needed without worrying about harm.

Here's what we're going to do about it:

Well Rehabilitation

The well marked for this overhaul is dry for a few months every year and needs major work to supply adequate, clean water to the community year round. The pump will be removed, and a hand auger will be lowered inside and powered by a drill team. This hand auger will allow the team to drill several meters deeper to hit a sufficient water column that will ensure the well supplies water throughout all seasons.

As the team drills, casing will be installed, transforming the bottom of this hand-dug well into a borehole. PVC piping will connect this lower system directly to the pump, a construction that we know will also improve the quality of water.

Once this plan is implemented, everyone within the community will have access to safe drinking water in both quality and quantity, even through the dry months.

Hygiene and Sanitation Training

There will be hygiene and sanitation training sessions offered for three days in a row.

After our visit, the hygiene and sanitation trainer decided it would be best to teach community members how to build a tippy tap (a hand-washing station built with a jerrycan, string, and sticks). They will use these tippy taps for handwashing demonstrations, and will also teach about other tools like dish racks and the importance of properly penning in animals.

These trainings will also strengthen the water user committee that manages and maintains this well. They enforce proper behavior and report to us whenever they need our help solving a serious problem, like a pump breakdown.

Project Updates


April, 2024: Komrabai Community Well Rehabilitation Complete!

We are excited to share that a safe, reliable water point at Komrabai Community in Sierra Leone is now providing clean water to community members! We also conducted hygiene and sanitation training, which focused on healthy practices such as handwashing and using latrines.

"I am happy to have access to safe water in my community. Before, I walked a long distance to access water, especially [from] the swamp. Sometimes, I [would] come across a snake, but today, I will not be walking a long distance to access water, and I will not come across a snake anymore. Going to school on time and the burden of fetching water [for] home was a big problem for me. Now this water well is close to my house, and I will fetch enough water [for] home and go to school on time," shared 16-year-old Mbalu.

Mbalu celebrating clean water!

Adults feel relief from their heavy burden as well!

Mabinty Kamara, a 39-year-old trader, was eager to share her joy. "Today, I am happy because I have access to safe drinking water. Before, I found it difficult to access safe water, and sometimes, when I drank such water, I experienced strange symptoms that would cause me to seek medical treatment. This would cause me to spend a lot of money to regain my health. But with this water point and when I drink this water, I will not experience such. Walking long distances to access water hurt my legs but today I will no longer walk a long distance."

Mabinty Kamara (red shirt) is excited for the rehabilitated well!

"Now that I have access to this water well, I will prepare food on time for my family, launder clothes, fetch safe drinking water and I will do my business normally," she continued.

We held a dedication ceremony to officially hand the well over to the community. Several local dignitaries attended the ceremony, including representatives Osman Fofanah, a Mapping Officer of the Ministry of Water Resources, and Councilor Dauda Ansumana Sawanneh. Stakeholders and community members were also there to witness the dedication. Each official gave a short speech thanking everyone who contributed to the rehabilitation of the water project and reminding everyone to take good care of it. Then, Mbalu and Mabinty made statements on their community's behalf. The ceremony concluded with celebration, singing, and dancing.

Community members singing and dancing in celebration!

Clean Water Restored

The drill team arrived the day before beginning work. They set up camp and unpacked all their tools and supplies to prepare for drilling the next day. The community provided space for the team to store their belongings and meals for the duration of their stay. The following day, the work began.

First, we raised the tripod, the structure we use to hold and maneuver each drilling tool. Next, we measured the well's original depth. We then socketed the pipes and installed a casing.

Finally, we lined up the drill rods and started to drill! We reached a final depth of 15.7 meters with water at 8 meters. The hand-drill method allowed the team to install the cylinder far below the aquifer so that the community has excellent water access throughout the year.

After drilling was complete, we installed screening and a filter pack to keep out debris when the water was pumped. We then cemented an iron rod to the well lining and fixed it with an iron collar at the top.

Next, we bailed the well by hand for three days and flushed it, clearing any debris generated by the drilling process. Finally, we tested the yield to ensure the well would provide clean water with minimal effort at the pump.

As the project neared completion, we built a new cement platform, walls, and drainage system around the well to seal it off from surface-level contaminants. The drainage system helps to redirect runoff and spilled water to help avoid standing water at the well, which can be uncomfortable and unhygienic and a breeding ground for disease-carrying mosquitoes.

At last, we installed the pump and conducted a water quality test. The test results showed that this was clean water fit for drinking!

New Knowledge

Before conducting any hygiene training, we called and visited the local water user committee to understand the community’s challenges and lack of sanitation facilities. We shared the findings from our discussions with the committee members to help them make the necessary adjustments before the training began. For example, we identified households without handwashing stations or ones that may need to repair their latrines. With this information, community members worked together to improve hygiene and sanitation at home.

After this preparatory period, we scheduled a time for members from each household using the water point to attend three days of hygiene and sanitation training. We then dispatched our teams to the agreed-upon location to hold the meeting.

Handwashing training.

Training topics covered included handwashing and tippy taps, good and bad hygiene habits, teen pregnancy, worms and parasites, proper dental hygiene, menstrual hygiene, proper care of the well's pump, keeping the water clean, the cost recovery system, the importance of using dish racks and clotheslines, the importance of toilets, keeping latrines clean, balanced diets, the diarrhea doll, and disease transmission and prevention, COVID-19, Ebola, Hepatitis, HIV and AIDS.

One topic that was particularly life-changing for some community members was oral hygiene. Much of the older generation within the community had only used "chewing sticks" and ash or charcoal to clean their teeth. "A community member asked, 'Now that I am about to see my ancestors, will I be able to adapt to this change by using the toothbrush to clean my old teeth?' This was amusing for everyone, but the truth of the matter was made known to her and other participants. The need for change was seen in her contribution and the questions she asked. This alone makes other participants have it in mind that positive changes are possible," shared field Officer Alie Kamara.

Dental hygiene lesson.

Mabinty, quoted above, shared how the hygiene and sanitation training impacted her life. "Training [was] valuable to me and the entire community. The facilitators have impacted [my] knowledge and [I] am happy for that because this will bring positive change in my life. The new knowledge the facilitators have impacted on me will be helpful for me if I put them into practice. It will help me to tackle the negative effects of diarrhea, typhoid, [and] worms, and how to cure them. This training has also helped me on how to hang [a] bed net so mosquitoes will not bite us. I will change all bad hygiene practices that I used to do before this training."

Conclusion

This project required a substantial collaboration between our staff, our in-country teams, and the community members. When an issue arises concerning the well, community members are equipped with the necessary skills to rectify the problem and ensure the water point works appropriately. However, if the issue is beyond their capabilities, they can contact their local field officers to assist them.

Also, we will continue to offer them unmatchable support as a part of our monitoring and maintenance program. We walk with each community, problem-solving together when they face challenges with functionality, seasonality, or water quality. Together, all these components help us strive for enduring access to reliable, clean, and safe water for this community.

With your contribution, one more piece has been added to a large puzzle of water projects. In Kenya, Uganda, and Sierra Leone, we’re working toward complete coverage. That means reliable, maintained water sources within a 30-minute round trip for each community, household, school, and health center. With this in mind, search through our upcoming projects to see which community you can help next!

Thank you for making all of this possible!




February, 2024: Komrabai Community Well Rehabilitation Underway!

The lack of adequate water in Komrabai Community costs people time, energy, and health every single day. Clean water scarcity contributes to community instability and diminishes individuals’ personal progress.

But thanks to your recent generosity, things will soon improve here. We are now working to install a reliable water point and improve hygiene standards. We look forward to sharing inspiring news in the near future!
